日本（PRO-face）中國普洛菲斯代理PFXGP6500TAA

聯系方式：郭工 18616038825

Main

Product or component type

Touch panel screen

Range of product

Pro-face GP6000

Software package

GP-Pro EX

Processor name

ARM Cortex-A53

Complementary

Display size

10.4 inch

Display type

Colour TFT LCD

Display colour

16 million colours

Display resolution

800 x 600 pixels SVGA

Touch panel

Single touch analogue resistive

Backlight lifespan

50000 hours with white

Brightness

101 levels via touch panel
101 levels by software

Character font

Japanese
ASCII
Chinese (simplified Chinese)
Chinese (traditional Chinese)
Korean
Cyrillic
Thai

Input voltage limits

85...264 V AC

Rated short-duration power frequency withstand voltage

1.5 kV AC during 1 min

Local signalling

Status LED green, steady for operating
Status LED green, steady for operating status (RUN)
Status LED orange, flashing for software starting up
Status LED red, steady for power ON
Status LED red, flashing for ERR (Error)
Status LED green, flashing for backlight and display off

Memory description

Built in flash memory 4 GB
Backup memory NVRAM 512 KB

Memory description

Backup memory NVRAM 512 KB

Type of cooling

AN (air natural)

Integrated connection type

COM1 serial link 1 SUB-D 9-pin male, interface: RS232C, transmission rate: 2400...115200 bps
COM2 serial link 1 SUB-D 9-pin male, interface: RS422/RS485, transmission rate: 2400...115200 bps
COM2 serial link 1 SUB-D 9-pin male, interface: RS422/RS485, transmission rate: 187.5 kbps
USB 2.0 type A
USB 2.0 type micro B
Ethernet 2 RJ45, interface: 10base-T/100base-TX
SD/SDHC/SDXC

[Us] rated supply voltage

100...240 V AC

Inrush current

30 A

Maximum power consumption in W

maximum
backlight off (standby mode)

Power consumption in VA

18.3 VA at 100 V AC (maximum)
29.1 VA at 240 V AC (maximum)

Electrical connection

Cable 3.5 mm², AWG 18...AWG 12, max resistance 100 Ohm for protective earth

Fixing mode

By 4 installation fasteners, mounting on 1.6...5 mm thick panel

Cut-out dimensions

259 x 201 mm panel cut dimension

Width

272.5 mm

Height

214.5 mm

Depth

58.5 mm

Product weight

1.9 kg

Environment

Standards

EN 61000-6-4
EN 61000-6-2
EN 61131-2
UL 61010-2-201
CSA C22.2 No 61010-2-201
UL 121201
CSA C22.2 No 213

Directives

2014/35/EU - low voltage directive
2014/30/EU - electromagnetic compatibility
2014/34/EU - ATEX directive
2012/19/EU - WEEE directive
2011/65/EU - RoHS
2015/863/EU - RoHS directive

IP degree of protection

IP65f (front panel (in enclosure)) conforming to UL 50
conforming to UL 50 E

Ambient air temperature for operation

0…55 °C

Ambient air temperature for storage

-20…60 °C

Relative humidity

10…90 % non condensing

Storage Relative Humidity

10…90 % non condensing

Operating altitude

2000 m

Pollution degree

2

Environmental characteristic

Corrosive gas free

Vibration resistance

3.5 mm (f = 5…9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to EN/IEC 61131-2
9.8 m/s² (f = 9…150 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to EN/IEC 61131-2

Shock resistance

147 m/s² (X, Y, Z directions for 3 times) conforming to EN/IEC 61131-2

Insulation resistance

> 10 MOhm

Electromagnetic compatibility

Electrostatic discharge immunity test - test level: 6 kV (contact discharge) conforming to EN/IEC 61000-4-2 level 3

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

14 cm

Package 1 Width

28.2 cm

Package 1 Length

36.2 cm

Package 1 Weight

2.5 kg

Unit Type of Package 2

S04

Number of Units in Package 2

4

Package 2 Height

30 cm

Package 2 Width

40 cm

Package 2 Length

60 cm

Package 2 Weight

11.2 kg

Offer Sustainability

Schneider Electric aims to achieve Net Zero status by 2050 through supply chain partnerships, lower impact materials, and circularity via our ongoing “Use Better, Use Longer, Use Again” campaign to extend product lifetimes and recyclability.

Environmental Data Explained

Recyclability potential, in %

33

Total lifecycle Carbon footprint

1 016 kg CO2 eq.

Carbon footprint of the manufacturing phase [A1 to A3]

129 kg CO2 eq.

Carbon footprint of the distribution phase [A4]

0.5 kg CO2 eq.

Carbon footprint of the installation phase [A5]

0.1 kg CO2 eq.

Carbon footprint of the use phase [B2, B3, B4, B6]

883 kg CO2 eq.

Mercury free

Yes

Sustainable packaging

No

Carbon footprint of the end-of-life phase [C1 to C4]

4 kg CO2 eq.

Environmental Disclosure

Product Environmental Profile

Total lifecycle Carbon footprint

1016

F-gas free

only air and vacuum used for insulation / breaking, no F-gas including SF6

Average percentage of recycled metal content

95 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

SCIP Number

Dc3bb0a9-4a86-4143-a0f0-728f535 A2c12

REACh Regulation

https://download.se.com/files?p_Doc_Ref=PFXGP6500TAA_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29

EU RoHS Directive

https://download.se.com/files?p_Doc_Ref=PFXGP6500TAA_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29

California proposition 65

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Halogen-free status

Product contains halogen above thresholds

PVC free

No

Silicone-free

No

End of life manual availability

End of Life Information

Removable battery

User replaceable

Take-back

No
